Cost Effective Wedding Planning Led Video Wall Stage Led Display Screen Rental P2 P3 P4 Led Wall Rental
Production Description
1. Classical and stable structure and performance.
2. Two patent protected strong locks design, realizing combination of reliability and security.
3. Die-casting aluminum body, light weight for easy transportation and high accuracy installation.
4. Perfectly be compatible with any existing controller and without screen shaking/quick flashing/mosaic problems.
5. Supporting installation of hanging/ground mounting, for stage/TV show/studio, and other event applications.
6. Tool free assembly and disassembly.
| Value | P2.6 | P2.9 | P3.9 | P3.9 | p4.8 |
| Pixel pitch (mm) | 2.6 | 2.9 | 3.91 | 3.91 | 4.81 |
| Pixel configuration | SMD | SMD2121 | SMD2020 | SMD2020 | SMD2020 |
| Brightness (nits) | 1000 | 1000 | 1000 | 1000 | 1000 |
| Pixel Matrix Per Panel | 192 x 192 | 172 x 172 | 128 x 128 | 128 x 256 | 104 x 208 |
| Pixel Matrix Per Sq.m | 147929 | 118906 | 65536 | 65536 | 43264 |
| Viewing Angle (H/V) | 120/120 | 120/120 | 120/120 | 120/120 | 120/120 |
| Refresh rate (Hz) | ≥1920 | ≥1920 | ≥1920 | ≥1920 | ≥1920 |
| IP grade ( F / R) | IP40 / IP40 | IP40 / IP40 | IP40 / IP40 | IP40 / IP40 | IP40 / IP40 |
| Input voltage ( V ) | AC220V ± 10% | AC220V ± 10% | AC220V ± 10% | AC220V ± 10% | AC220V ± 10% |
| Power Consumption (Max / Avg) | 460/ 160 w/sq.m | 600/180 w/sq.m | 460/ 160 w/sq.m | 260/ 100 w/sq.m | 580/ 230 w/sq.m |
| Size (L x W x D mm) | 500*500*82.5 | 500*500*82 | 500x500*82.5 | 500x1000*75 | 500x1000x75 |
| Panel weight (Kgs) | 6.8 (Die-casting Al.) | 8.4 (Die-casting Al.) | 6.8 (Die-casting Al.) | 13.5 (Die-casting Al.) | 15.7 (Die-casting Al.) |
| Curved | yes | yes | yes | no | no |
SCX Hot Selling
♦ Production process:
1) Incoming Inspection→2) SMD→3) Plug-in
→4) Wave Soldering→5) After Welding→6) Testing
→7) Semi Finished Aging→8) Module Assembly
→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing
♦ Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.
♦ Why choose us:
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.
♦ Frequently Asked Questions
What kind of payment terms you can accept ?
We can accept T/T and Western Union.
What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of
our products continuity.
Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure
our led display’s competitiveness.
Our team will be forever here to offer you full supports
Product Tags:
|
|
Wedding Decoration Indoor HD Rental LED Display P2 P3 P4 128 * 64 Resolution Images
|
