Outdoor Rental P3.91 LED Display For Churches, Shows, Events And Weddings
It's has own advantage as follows:
1.250 x250mm led module .( adopt epistar chip from taiwan. Nation star led light)
2.500mm x 500mm die cast aluminum cabinet. you can assemble the led display into different size.
3.Air plug design,all kinds of the led display cabinet can be assembled and dismantled easily.
4. 3 years warranty, more than 10 years lifeuse .3% spare parts will be available.( such as ,connection piece, air plug .led module, ribbon cable, wire line .power supply)
The detailed parameter of indoor P3.91 stage led display as follows.
| LED Lamps | Type | SMD2121 (High Brightness LEDs) |
| LED Standard | Real Pixel(1R1G1B) |
| Red Wavelength | 625-630nm |
| LED Module | Pixel Pitch | 3.91mm |
| Module Size | 250mm x250mm |
| Module Resolution | 128*256 |
| LED Cabinet | Cabinet Size | 500mmX500mm |
| Cabinet Resolution | 128pixels *128pixels |
| Cabinets Material | Sealed Iron Cabinet |
| led screen | Pixel Density | 65410pixels/sq.m |
| Drive IC | MBI5124 |
| Power Supply | Series connection |
| Brightness | >2500cd/sqm |
| Display Color | 16.7million |
| Viewing Angle | 160°(Horizontal),110°(Vertical) |
| Best Viewing Distance | 3m~200m |
| Max Power Consumption | 600 w/sq.m |
| Weight | 22kgs/sq.m |
| Refresh Rate | 3000hz |
| Input Voltage | AC220V/50H or AC110V/60H |
| Output Voltage | DC5V,40A |
| Grey Scale Levels | 16bit |
| Display Colors | R(1024) x G(1024) x B(1024) |
| MTBF | 10,000 hours |
| Life-span | 100,000 hours |
| Drive Mode | 1/16 scaning |
| Working Humidity | 10%~99% |
| Control System | Control method | Synchronization & Asynchronization |
| Control System | (software) linsn |
| Software | LED Studio |
| PC Operating system | Microsoft Windows 7, 98, 2000, XP and Vista |
The 250mm x2500mm led module as follows.
You can connect the led cabinet with each other easily.
At this time, the die cast aluminum is very popular,it’s less weight ,easy to be assemble and dismantle.with flight case packaged,it’s good for for rental and hang usage. Because of new technical usage,the price is very competitive.if you are interested,please feel free to contact Sherlock(very kind-heart person)
Q1. What's the warranty of your LED Display Screen ?
A1. We have a 3-years warranty for our led display screen, and 100,000 hours life span of the led lamps.
Q2. What about your pre-sale service and post-sale service?
A2. For pre-sale service. We have a professional sales team and a 8 years technical team who are willing to answer your question 24/7.
We can offer a whole complete solution for your project!
For post-sale service. We can instruct you how to use, adjust the screens, and change the boken modules with spare parts.
Also, we can send technicals to your country to solve problems. Mostly, our led display will not have big problems within warranty time!
